HURST KL-32 - Unit in Detail

10
4.2 Unit in detail
1 Star grip
2 Control valve
3 Spreader body
4 Handle
5 Hand guard
6 Spreading arm
7 Tip with borehole for chain set
8 Interlock bolt
9 Pressure hose
10 Return hose
11 Handhold
12 Mono-coupling male
13 Quick-disconnect coupling (male)
14 Quick-disconnect coupling (female)
1
14
13
quick-disconnect coupling
system:
2
3
4
5
6
7
8
9
10
11
12
6
8
