26
2. Remove the cover from the couplings.
10.3.4 Mono-couplings
The mono-couplings must be replaced in the event of:
- external visible damage,
- the locking device not working,
- hydraulic fl uid continually leaking in a coupled/uncoupled state.
During assembly, tighten the connection nut of the hose assembly with a torque of M
A
= 40 Nm
/ 29.5 ft.lbs..
Procedure:
1. Remove the screws ‘A’.
WARNING / CAUTION!
Never repair couplings: they are to be replaced by new original HURST parts!
A
A
3. Loosen the connection nuts of the hose assembly and remove the coupling.
