FUEL SYSTEM
G
4
– Remove the screws (1) with special tool
800.29.052.000 and take off the throttle sensor (2).
NOTE: Only remove the throttle sensor if it is
defective. The throttle sensor must be
readjusted if the screws (1) are loosened.
– Remove the screw (3) and pull the connecting piece
out of the carburetor.
– Remove the 2 screws and take the intake trumpet and
the O-ring (4) off of the carburetor.
– Unscrew the idle-air jet (5) and main air jet (6).
– Thoroughly clean all of the jets and the other parts
and blow through with compressed air.
–Clean the carburetor housing and blow compressed
air through all of the ducts in the carburetor.
– Check all of the gaskets for damage and replace if
necessary.
1
1
2
3
4
5
6
