Huskee 26750TSC User Manual

21
Operator's Manual
26750TSC Compact Tiller
For additional information email info@ardisam.com or call 800-345-6007 M-F 8-5
REF.
NO.
PART # DESCRIPTION QT Y.
1 18004 WELDMENT FRAME 1
2 13366 LOCK PIN WIRE BALE 1
3 92776 BOLT M6 X 1.0 X 20 HHCS GR8.8 ZN 2
4 18010 HANDLEBAR LOWER STRAP 1
5 W1265V0904 BOLT M8 X 1.25 X 20 HHCS ZN GR8.8 2
6 3245 WASHER M8 8.4MM X 24MM X
2.2MM ZN
2
7 3252 NUT M8 X 1.25 H GR8.8 ZN 4
8 W1265V0913 NUT M6 X 1.0 HNYLK GR8.8 ZN 10
9 3247 BOLT M8 X 1.25 X 45 HHFCS GR8.8 ZN 2
10 400024 WASHER FLAT M8 8.4 X 16 X 1.6
THK GR8.8 ZN
2
11 W1200117 WASHER M6 X 13 X 1.75 FLAT ZN 6
12 18123 WELDMENT GUARD PULLEY
LOWER
1
13 18103 BOLT M6 X 1.0 X 40 HH GR 8.8 ZN 4
14 331052 NUT M12 X 1.75 HH NYLCK GR8.8 ZN 2
15 W1200116 WASHER M6 X 1.5 SPRLCK ZN 2
16 18119 WELDMENT SHIELD TINE MIDDLE 1
17 10513 BOLT M12 X 1.5 X 96 HH SHLDR
M15.7 X 42
2
18 18118 WELDMENT SHIELD TINE RIGHT 1
19 18131 ASSEMBLY DRAG STAKE 1
20 18116 WELDMENT SHIELD TINE LEFT 1
21 18058 BOLT M6 x 1.0 x 12 SBHCS GR8.8 ZN 6
22 10517 WASHER 16MM ID X 25MM OD X
2.5 THK ZN
2
23 13163 WHEEL 8ID X 5/8ID IN RUBBER 2
CHASSIS ASSEMBLY PARTS LIST

Huskee 26750TSC Specifications

General

Brand	Huskee
Model	26750TSC
Category	Tiller
Language	English
