OPERATOR INSTRUCTIONS AND PARTS
MC43ETSC & MC43TSC Cultivator
Page 21
GetEarthquake.com
800-345-6007
MC43ETSC HANDLEBAR PARTS LIST
KEY PART # DESCRIPTION QTY.
1 300471 BOLT, M5 X 12MM 3
2 300523 GR
OUND WIRE 1
3 46139 KEY
ONLY 1
4 46140 KEY SWITCH 1
5 46141 BOL
T, HEX HD M8 X 1.25 X 160MM 2
6 4639 GRIP,
HANDLEBAR 2
7 4640 NUT, T-
HANDLE 4
8 4641 WASHER 8
9 4642 BOL
T, HANDLE CLAMP 4
10 4655 NUT
, HEX HD M8 X 1.25 2
11 4656 BATTERY BOX MC43E 1
12 4657 COVER, BATTERY BOX 1
13 4659 VOLTAGE RECTIFIER 1
14 4660 SOLENOID 1
15 4661 CHARGER PIGTAIL 1
16 4662 NUT, CHARGER PIGTAIL 1
17 4663 CAP, CHARGER PIGTAIL 1
KEY PART # DESCRIPTION QTY.
18 4667 THR
OTTLE CABLE 1
19 4669 BOLT, M6 X 1MM X 12MM PAN HD 1
20 4689 HANDLEBAR
, UPPER RIGHT 1
21 4690 HANDLEBAR
, UPPER LEFT 1
22 4693 HANDLEBAR
, MIDDLE 1
23 4695 HANDLEBAR
, LOWER 1
24 4814 BOLT, PHILLIPS TRUSS HD ZN 10-
24 X 1-1/4
1
25 4819 TRIGGER ASSEMBLY, LONG
THROW W/O CABLE
1
26 53106 NUT, LOCK BI-WAY 1/4-20 2
27 6041612 BOLT, PTH ZN 1/4-20 X 1-1/2 2
-- 46122 BA
TTERY 12V 7A (not shown) 1
-- 4653 FUSE
HOLDER (not shown) 1
-- 4658 FUSE
10 AMP (not shown) 1
-- 4675 BA
TTERY CONNECTOR SET, WHITE
(not shown)
1
-- 4681 BA
TTERY CHARGER (not shown) 1
