OPERATOR INSTRUCTIONS AND PARTS
MC43ETSC & MC43TSC Cultivator
Page 23
800-345-6007
KEY PART # DESCRIPTION QTY.
1 46141 BOL
T, HEX HD M8 X 1.25 X 160MM 2
2 4639 GRIP,
HANDLEBAR 2
3 4640 NUT, T-
HANDLE 4
4 4641 WASHER 8
5 4642 BOL
T, HANDLE CLAMP 4
6 4655 NUT
, HEX HD M8 X 1.25 2
7 4667 THR
OTTLE CABLE 1
8 4689 HANDLEBAR
, UPPER RIGHT 1
9 4690 HANDLEBAR
, UPPER LEFT 1
10 4693 HANDLEBAR
, MIDDLE 1
11 4695 HANDLEBAR
, LOWER 1
12 4814 BOLT, PHILLIPS TRUSS HD ZN 10-
24 X 1-1/4
1
13 4819 TRIGGER ASSEMBLY, LONG
THROW W/O CABLE
1
MC43TSC HANDLEBAR PARTS LIST
To Next Page
