OPERATOR INSTRUCTIONS AND PARTS
MC43ETSC & MC43TSC Cultivator
Page 27
800-345-6007
ENGINE PARTS LIST
KEY PART # DESCRIPTION QTY.
1 300484 FLYWHEEL, MAGNETO 1
2 300337 NUT, FLANGE M8 1
3 300462 WASHER, ROTOR 2
4 300413 CLUTCH ROTOR ASSEMBLY 1
5 300412 SPRING, CLUTCH 1
6 300449 WASHER, SPRING 2
7 300450 BOLT, SHOULDER 2
8 300467 PIN, LOCATING 2
9 300487 MOUNT RING & SHROUD 1
10 300491 RECOIL CLUTCH 1
11 300429 PLATE, RECOIL 1
12 3004121 HANDLE, STANDARD RECOIL 1
13 300430 RECOIL ASSEMBLY W/STANDARD HANDLE 1
14 300472 IGNITION COIL, MC43 1
300472CE IGNITION COIL, MC43 CE 1
300191 IGNITION
COIL, MC43E 1
300191CE IGNITION
COIL, MC43E CE 1
15 300482 SHROUD, ENGINE 1
16 300493 BOLT, STUD M6 X 62MM 2
17 300475 GASKET, MUFFLER 1
18 4813 MUFFLER 1
19 4812 COVER, MUFFLER 1
20 BM6A SPARK PLUG 1
21 300483 COVER, ENGINE SHROUD 1
22 300476 GASKET, INTAKE 1
23 300478 WINDPIPE, INTAKE 1
24 300479 GASKET, CARBURETOR 1
25 300486 CARBURETOR 1
26 300481 O-RING, CARBURETOR 1
27 3004109 PRIMER BULB 1
28 300329* INT
AKE BASE ASSEMBLY (includes intake
base, long choke lever, choke cover & throttle
lever screw)
1
29 300340* CHOKE LEVER, LONG 1
30 300328* CHOKE COVER 1
31 3004132* SCREW, THROTTLE LEVER 1
32 300455 PLATE, INTAKE COVER ADAPTER 1
33 300457 COVER, AIR FILTER 1
34 300435 AIR FILTER 1
35 300330 INTAKE COVER 1
KEY PART # DESCRIPTION QTY.
36 56105 BRACKET, GAS TANK 1
37 300331 GAS TANK 1
38 300401 GAS
CAP, MANUAL VENTING 1
39 300332 SHROUD, GAS TANK 1
40 1021 ROCKER SWITCH 1
-- 1021CE ON
/OFF SWITCH WIRE ASSEMBLY
REMOTE HANDLEBAR (NOT SHOWN)
41 300494 GROMMET, 2-HOLE GAS TANK 1
42 300497 HOSE, PRIMER LINE 1
43 300498 HOSE, FUEL LINE 1
44 300335 BOLT W/WASHER PHILLIPS HH 4
45 300492 NUT, FLANGE M6 2
46 300471 BOLT W/WASHER M5 X 12MM 5
47 300439 BOLT W/WASHER PH M5 X 18MM 7
48 300336 BOLT HH M5 X 18MM 4
49 300438 BOLT W/WASHER M5 X 25MM 2
50 300456 BOLT M5 X 50MM 2
51 300326 GUARD 1
52 300338 KEY, FLYWHEEL 1
53 3004103 FILTER, FUEL 1
61 3004158 COVER, AIR FILTER 1
62 30041501* BASE, AIR FILTER 1
63 3004156 FO
AM, AIR FILTER 1
64 3004157 PLA
TE, REINFORCEMENT 1
65 3004153* BOL
T, CHOKE LEVER 1
66 3004155* W
ASHER, CHOKE LEVER 2
67 3004154* NUT,
NYLOC, CHOKE LEVER 1
68 3004151* CHOKE
LEVER 1
69 3004152* CHOKE
PADDLE 1
* 3004150 A
IR FILTER BASE (sold as assembly unit only) 1
- 300410 KIT, TUNE-UP (includes spark plug, carb air
filter, fuel filter, bottle of Viper 2-cycle oil &
spark plug wrench)
1
- 300470 FUEL LINE HOSE & FILTER 1
- 3004114 KIT, CARBURETOR REPAIR 1
- 3004118 KIT,
GAS TANK (includes gas tank, both fuel
lines, fuel filter & 2-hole grommet)
1
MC43E ELECTRIC START MODEL ONLY
54 300525 STUD BOLT M6 X 41MM 1
55 300339 KEY, ELECTRIC STARTER 1
56 300527 ST
ARTER WIRE 1
57 300529 ST
ARTER MOTOR KIT (includes starter, stud
bolt, clutch drum & ground wire)
1
58 300445 W
ASHER M5 2
59 300438 BOLT W/WASHER M5 X 25MM 2
60 300439 BOLT W/WASHER PH M5 X 18MM 2
*For reference only. Contact customer service for replacement
* P/N 3004150 Air Filter Base sold as an assembly unit only.
