Prior To Installation
The distance from the back of the truck cab to the center of the King Pin (Dim X) should be
4” greater than one-half the trailer width (Dim Y)
If towing with a short bed truck less than 8ft, Husky Towing recommend the use of a Husky
Heavy Duty Roller for increased turning clearance at slow maneuvering speeds.
* Check the Truck Payload and Trailer Weight as defined in Appendix A
(Checking Truck & 5th Wheel Trailer Weight Rating). Never Overload
Truck, Trailer or Hitch.
* This Hitch requires Pre-Installed Base Rails which are bolted through the
Bed of the Truck into brackets which in turn are fastened to the Truck
Chassis. DO NOT INSTALL HITCH BY FASTENING TO THE FLOOR OF
THE PICKUP BOX. The Pickup Box Floor is not strong enough to carry the
loads imposed by the trailer
* This 5
th
Wheel Hitch is rated for a MAXIMUM Pin Weight of 4,000 lbs. and
a MAXIMUM Trailer GVW of 16,000 lbs. Exceeding Maximum ratings may
result in death, serious injury or property damage.
Warnings
