Assembly (continued)
8
Using two or more people, stand the workbench in its upright
position.
15.
Install the crank handle (C) into the shaft in the corner below the
wood top as shown.
12.
Install the drawers using the steps below
13.
□ Pull the slides and slide carrier out until fully extended.
□ Hold the slide on the cabinet while aligning it with
the slide on the drawer.
□
□ Slowly push the drawer until it is fully closed to
engage the slide.
□ Open the drawer and close it to verify proper
operation.
Slightly insert one side and repeat for the other side.
Remove the drawers using the steps below
14.
□ Fully extend and empty the drawer.
□ Depending on the slide, either lift or lower the
release lever on both sides so the slides can ride over
the stops. Pull out to remove.
