English – 9
TOOLS
Pos Description Used for Order No.
1 Piston assembly set Assembling the piston 502 50 70-01
2 Cover plate, inlet Sealing the inlet manifold 502 52 01-01
3 Cover plate exhaust Sealing the exhaust port 502 52 31-01
4 Pressure tester Produce pressure when leakage testing 502 50 38-01
5 Puller Removing bearings from the crankshaft 504 90 90-01
6 Piston stop Locking the crankshaft 502 54 15-01
7 Tachometer Adjusting the carburettor 502 71 14-01
8 Test spark plug Checking the ignition module 502 71 13-01
9 Feeler gauges, air gap Adjustment of the ignition module 502 51 34-02
10 Assembly bar Assembly of the spark plug guard 502 50 06-01
11 Hook for fuel filter Lifting out the fuel filter 502 50 83-01
12 Assembly fixture Assembling the chain saw 502 51 02-01
13 Punch Dismantling the flywheel 502 51 94-01
14 Allen key, 3 mm For M4 bolts 502 50 19-01
14 Allen key, 4 mm For M5 bolts 502 50 18-01
15 Hexagonal screwdriver, 3 mm For M4 bolts 502 50 86-01
15 Hexagonal screwdriver, 4 mm For M5 bolts 502 50 87-01
The tools listed here are service tools intended for use on the
chain saw in question. In addition to these tools, a standard set
of hand tools is required.
