Husqvarna CTH 164T Parts List

15
TRACTOR - MODEL NO. CTH 164T (96051010700), PRODUCT NO. 960 51 01-07
MOWER DECK
44
44
KEY PART
NO. NO. DESCRIPTION
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 580 46 53-02 Deck Weldment
3 873 90 05-00 Nut Lock Hex Flange 5/16 - 18
5 817 00 05-10 Bolt 5/16-18
11 532 13 77-29 Screw Thd Roll 1/4 - 20 X 5/8
13 872 11 06-12 Bolt Carr Sh 3/8 - 16 X 1 - 1/2 Gr. 5
14 532 15 60-85 Keeper Belt Idler
16 873 90 06-00 Nut Lock FlG 3/8 - 16 unc
17 532 40 02-34 Nut Flange Lock Top
18 532 18 76-90 Washer Spacer Mandrel
19 532 11 04-85 Bearing Ball Mandrel
20 532 17 39-84 Screw Thread Roll
23 817 49 06-28 Screw Thdrol 3/8 - 16 X 1-3/4
27 532 44 58-34 V-Belt Drive
32 532 44 62-05 Spring Return Deck
33 532 18 72-81 Housing Mandrel 4pt Service
34 532 19 28-72 Shaft Asm Mndrl N/Greaseable38
35 532 42 79-84 Blade Mower LH
36 532 19 30-03 Bolt/Washer Asm 7/16 - 20 unf
42 817 00 05-12 Bolt
43 532 19 97-89 Pulley Mandrel
45 532 13 71-52 Housing Mandrel
72 581 45 41-01 Chute Upper
75 532 13 14-94 Pulley Idler Flat
76 532 41 55-98 Washout Port
80 532 42 30-62 Palnut 1/4
84 532 40 01-40 Keeper Belt Mandrel
85 532 42 79-85 Blade Mower RH
86 532 18 17-13 Bolt 3/8-24 x 1.50 Gr. 8
87 810 03 06-00 Washer Lock Hvy 3/8
88 532 14 02-96 Washer Hard Blade Mower Vented
91 819 13 20-12 Washer 13/32 x 1-1/4 x 12 Ga.
94 532 19 72-50 Bracket Clutch Cable
95 817 00 06-12 Bolt
96 532 40 02-71 Spacer
97 532 18 20-61 Shield Idler Mower
98 532 19 51-61 Stud Fastener
99 532 19 51-86 Arm Suspension Mower Rear
100 532 19 65-39 Bolt Shoulder
101 873 68 09-00 Nut Crownlock 9/16 - 18 unc
102 532 40 25-11 Spacer Bearing Swing Plate
103 532 43 69-92 Guard Front Vent
104 532 43 89-68 Mandrel Cover RH
105 532 43 87-44 Mandrel Cover LH
110 532 41 53-56 Gear Output
111 532 43 69-79 Gasket Gearcase
112 532 44 38-52 Shaft Gearcase
113 532 43 85-33 Plug Oil
114 532 43 85-34 Valve Relief
115 818 03 10-16 Screw Torx #10-24 x 1
116 872 11 04-14 Bolt 1/4-20 x 1.75 Gr. 5
117 873 90 04-00 Nut Hex Flange 1/4-20 unc
118 532 43 69-89 Arm Clutching
119 532 43 81-66 Gearcase Subasm
120 532 43 69-91 Keeper Belt RH
121 532 43 69-85 Washer
124 532 43 69-86 Non Greasable Mandrel Shaft
125 532 43 69-94 Bracket
127 532 19 34-06 Bolt Shoulder 3/8-16 x 3-5/8 Gr. 5
128 532 17 48-73 Wheel Guage
129 532 44 32-37 Rod Anti-Sway
130 819 13 13-12 Washer 13/32 x 13/16 x 12 Ga.
131 532 19 42-08 Pin Cotter 5/16 Bow Tie Lock
143 532 43 55-38 Door Mulch
144 532 43 58-61 Pin Hinge
145 532 43 79-88 E-Ring 5/16
146 532 44 58-96 Spring
252 581 55 44-02 Plate 97 Left Bolt Reinforcing
253 581 55 45-02 Plate 97 LHS Bolt Reinforcing
254 581 55 47-02 Plate 97 RHS Bolt Reinforcing
255 539 10 98-00 Carriage Bolt 1/4 - 20 x 1 Gr. 5
- - 532 19 28-70 Mandrel Assembly (Includes
housing (Key# 14), shaft assem-
bly (Key# 13), and bearing (Key#
15) only - pulley/nut/washer and
blade bolt/washers not included)
- - 532 44 79-01 Replacement Mower Complete
