19
TRACTOR - MODEL NO. CTH 164T (96051010700), PRODUCT NO. 960 51 01-07
BAGGER
46
KEY PART
NO. NO. DESCRIPTION
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
1 532 42 86-10 Tube Handle Bagger
2 532 44 75-72 Applique Bagger
3 532 17 48-14 Nut Push
5 532 44 37-62 Frame Asm Top Bagger
7 873 90 04-00 Nut Hex Flange 1/4-20 unc
8 532 44 75-75 Bagger Top
10 532 44 37-55 Frame Front
19 532 19 42-08 Cotter Pin 5/16 Bow Tie
21 532 44 59-43 Bag Asm
25 532 44 55-28 Latch Bagger
26 817 49 04-12 Screw Hexwsh Thdrol 1 14~20 x 3/4
27 532 44 55-29 Grommet Rubber
28 532 16 57-87 Grip Handle Black
42 532 44 04-28 Christmas Tree Clip
43 532 12 68-75 Clevis Pin
44 532 19 96-87 Bolt 1/4-20 1.50
45 532 44 37-54 Upper U Frame Weldment
46 532 44 55-41 RT Bagger Corner Close-Out
47 532 44 40-79 LH Bagger Corner Close-Out
48 532 44 40-80 Top Bagger Side Close-Out
49 532 17 18-73 Bolt Shoulder 5/16~ 18 TT
50 532 17 18-77 Bolt 5/16-18 unc x 3/4 W/SEMS
51 872 11 05-06 Bolt RDHDSQNK 5/16-18 unc x 3/4
52 873 80 05-00 Nut Lock HX W/INS 5/16-18 unc
53 532 44 41-95 Bracket Dump Handle
54 532 44 72-18 Bagger TOP Front Handle
55 872 14 05-12 Bolt Rdhd Sq 5/16-18 UNC x 1 1/2
56 532 42 03-06 Pin Clevis .1830DX1.26 long
58 532 08 51-79 Clip Retainer PM
59 532 44 47-63 Bagger Spread Tube
69 532 42 18-01 Screw
70 817 00 06-12 Bolt 3/8-16 x 3/4
83 873 80 06-00 Nut Lock 3/8-16 unc
84 872 11 06-08 Bolt 3/8-16 x 1
85 581 31 44-02 Bracket RH Pivot
86 581 31 43-02 Bracket LH Pivot
87 581 31 48-02 Bracket RH
88 581 31-47-02 Bracket LH
89 581 31 51-02 Weldment Offset Strut
