Husqvarna CTH 164T Parts List

7
TRACTOR - MODEL NO. CTH 164T (96051010700), PRODUCT NO. 960 51 01-07
CHASSIS AND ENCLOSURES
39
39
KEY PART
NO. NO. DESCRIPTION
3 532 43 97-52 Applique
5 532 43 74-84 Dash
14 532 44 11-77 Hood
15 532 43 97-33 Lens LH
18 532 43 77-62 Grille
25 532 44 33-85 Lens RH
34 580 91 09-01 Plate Engine
36 817 06 05-12 Screw 5/16-18 x 3/4
37 532 44 14-19 Fender
52 873 68 05-00 Nut Lock 5/16-18
62 872 11 06-08 Bolt RdHd Sqnk 3/8-16 x 1 Gr. 5
68 817 49 05-08 Screw Thdrol 5/16-18 x 1/2
118 819 13 13-16 Washer 13/32 x 13/16 x 16 Ga.
119 873 68 06-00 Nut Crownlock 3/8-16 unc
130 532 41 63-58 Screw #10 x 0.750
137 532 40 75-90 Bumper Dash
150 532 43 97-31 Air Duct
151 532 43 66-70 Bracket Pivot
152 532 43 98-70 Shield Browning
159 817 00 06-12 Screw Hexwsh Thrd 3/8-16 x 3/4
162 532 14 24-32 Screw
175 532 19 63-04 Crossmember
176 532 40 07-76 Screw 10-24 x 5/8
177 532 19 52-27 Bushing Steering
178 532 19 97-82 Cargo Asm. Net
180 583 90 27-01 Chassis
182 532 43 89-67 Dash Lower
183 874 52 05-20 Bolt 5/16-18 x 1-1/4
189 817 00 05-12 Screw 5/16-18 x 3/4
191 532 43 74-55 Insert Reflective RH
194 873 90 05-00 Nut Lock Hex Flange 5/16-18
195 532 40 41-37 Plug Hole Dash Lower
198 532 44 15-52 Indicator
199 532 41 87-39 Plate Deck Lift
202 532 43 97-28 Vent Side Hood RH
203 532 43 97-27 Vent Side Hood LH
204 532 44 06-65 Vent Top Hood
205 532 43 97-30 Skirt Hood Side RH
206 532 43 97-29 Skirt Hood Side LH
207 532 43 97-34 Bezel RH
NOTE: All component dimensions given in U.S. inches
1 inch = 25.4 mm
208 532 43 97-35 Bezel LH
213 874 76 05-12 Bolt 5/16-18 x 3/4
214 532 19 91-45 Clip Retainer Tinner
217 532 40 91-67 Rod Pivot
218 532 19 63-95 X-Piece Hood Stop
228 532 19 51-61 Stud Fastner
229 532 44 14-63 Lid Ext.
234 532 40 47-42 Bumper Hood
235 532 40 61-29 Spacer Fender
236 873 93 05-00 Nut Lock 5/16-18 unc
282 532 41 41-10 Clip Retainer
283 532 44 72-12 Console Deck Lift LH
284 532 44 72-20 Console Shft SRD RH
287 817 60 04-06 Screw 1/4-20 x 3/8
297 532 43 74-56 Insert Reflective LH
308 532 17 18-77 Bolt 5/16-18 unc x 3/4
309 581 32 89-02 Backplate
319 581 31 39-05 Lever Bagger
334 532 44 25-37 Bracket Engine
335 532 44 82-04 Cover RH Lower Close Out
336 532 44 53-09 Cover LH Lower Close Out
338 532 43 66-40 Bolt Shoulder
339 532 43 66-41 Lever Bagger Full
340 581 32 90-01 Door Pnt Battery tray Tex CRD
342 532 43 59-38 Supprt Fender
343 532 44 07-49 Clip
344 532 43 89-70 Control EZ Mulch
345 532 44 06-39 Knob
347 532 44 58-32 Hitch
349 532 43 66-06 LRVB Fuel Tank Support
350 532 44 51-43 Clip X-mas Tree
366 581 31 46-02 Bracket RH FR Bagger
367 581 31 45-02 Bracket LH FR Bagger
368 581 42 48-01 Shroud
KEY PART
NO. NO. DESCRIPTION
