English
–
3
Ser
vice journal
Pre-deliver
y service
1
Charge the battery for 4 hours at max. 3 amp.
2 Fit the venting hose on the battery.
3 Fit steering wheel, seat and any optional
equipment.
4 Check and adjust tyre pressure (60 Kpa, 0.6 bar,
9 PSI).
5 Adjust cutting unit:
Adjust lift springs (effective weight of cutting unit
should be 12-15kg / 26.5-33 lb).
Adjust cutting unit so that rear edge is about 2-4
mm / 1/8” higher than front edge.
Adjust cutting unit height setting so that cutting
height limit is 5 mm / 3/16” above the frame of the
unit at the lowest cutting height.
6 Check that the right amount of oil is in the engine.
7 Check that there is oil in the transmission’s oil
tank.
8 Connect battery.
9 Fill with fuel and start engine.
10 Check that machine does not move in neutral.
11 Check the synchronisation between the front and
rear wheels. (Only AWD-machines) See the
workshop manual.
12 Check:
Forward drive.
Reverse drive.
Operation of blades.
Seat safety switch.
Lif lever safety switch.
The safety switch for the hydrostat pedals.
13 Bleed the hydraulic system of excess air, top up
with oil if necessary.
14 Tell customer about:
Needs and benefits of following the service
schedule.
Servicing and the influence of this journal on the
second-hand value of the machine.
Range of applications for BioClip.
Complete proof of sale etc.
Pre-delivery service carried out. No outstanding
problems. Certified:
__________________________________________________________
Date, mileage, stamp, signature
After the first 8 hours
1
Change engine oil
2 Changing the gearbox oil (Only AWD-machines)
3 Check the synchronisation between the front and
rear wheels. (Only AWD-machines)
