WHAT IS WHAT?
What is what on the ride-on mower
12 3 4 5
7
6
8
10
13 15
14 1611 12
9
1 Speed limiter for driving forward
2 Speed limiter for reversing
3 Lifting lever for the cutting unit
4 Cutting height adjustment lever
5 Ignition lock
6 Throttle trigger
7 Choke control
8 Counter: 322T AWD
9 Cover lock
10 Parking brake
11 Lock button for parking brake
12 Seat adjustment.
13 Lever to disengage the driving front axle: 322T AWD
14 Fuel cap
15 Battery
16 Lever to disengage the drive Rider 220T
Lever to disengage the driving rear axle, 322T AWD
