English – 17
PRESENTATION
Release lever
The release control must be pulled out in order for the
machine to be moved when the engine is shutoff.
Should you attempt to drive the machine with the clutch
controls pulled out it will not mo
ve. The drive on the axle is
disengaged when one of the controls is pulled out.
Pull the controls to the end positions, do not use an
inter
mediate position.
Clutch control Rider 322T AWD
Rider 316T AWD and Rider 316Ts AWD have one control for
the front axle and one control for the rear axle.
• Clutch control, rear axle
- Control drawn out, drive system disengaged.
- Control depressed, drive system engaged.
• Clutch control, front axle
The control is positioned on the inside of the left front
wheel.
- Rear control (pulled out), drive system disengaged.
- Front control (pushed in), drive system engaged.
Release lever Rider 220T
• Pull out the control to disengage the drive system.
Push in the control to engage to the drive system.
IMPORTANT!
Always drive the machine with both clutch controls pressed
in.
