Husqvarna SMR 450 User Manual

D.8 Part. N. 8000 B0148 (02-2008)
SETTINGS AND ADJUSTMENTS
SMR 450-R
7
Adjustment of starter decompression device
In order to adjust the lever decompressor free play (approximately 3 mm - 0.12
in.): should the clearance be incorrect, unblock the counter ring-nut and turn the
adjusting screw (by unscrewing it, the clearance is reduced, while by screwing
screw it is increased); the lever holder (5) is provided with the adjuster (6); the
adjustment can be also effected with the tightener (7) on the R.H. side of the
engine (use this tightener if it is not possible to obtain the correct free play with
the adjuster on the handlebar).

Husqvarna SMR 450 Specifications

General

Engine Type	Single cylinder, 4-stroke
Clutch	Wet multi-disc, hydraulic
Front Brake	Single disc, 310 mm
Rear Brake	Single disc, 220 mm
Front Tire	120/70 R17
Rear Tire	150/60-17
