SETTINGS AND ADJUSTMENTS
Part. N. 8000 B0148 (02-2008) D.35
Handlebar position change (SMR 450-R)
The handlebar can be moved to suit your driving style. To effect these operations,
remove the upper screw (3), upper clamp (1), lower screw (4) then lower clamp
(2).
Turn the lower clamp (2) 180° to move forward or backward (10mm- 0.04in.) the
handlebar position with respect to the original setup.
Once these operations are completed, tighten the screws (3) to 2,75-3,05 kgm
(27-30 Nm; 19.9-22 Lb/fts) and the screws (4) to 2,0-2,2 kgm (19,6-21,6 Nm; 14.5-
15.9 Lb/fts).
1
2
3

Husqvarna SMR 450 Specifications

General

Engine Type	Single cylinder, 4-stroke
Clutch	Wet multi-disc, hydraulic
Front Brake	Single disc, 310 mm
Rear Brake	Single disc, 220 mm
Front Tire	120/70 R17
Rear Tire	150/60-17
