OVERHAULING AND MODIFYING THE CARTRIDGE AND BOTTOM VALVE
SETTING
CARTRIDGE OVERHAULING (REBOUND BRAKING)
Dismantling
nut.
( 37 ), the piston ( 36 ) complete with the segment ( 35 ), the washer ( 34 ) and
the spring ( 33 ), following this order.
Assembling:
The washers ( 37 ) and the piston ( 36 ) are the ones causing the rebound
braking. It is possible, if needed, to modify the fork’s behaviour during
the rebound phase, by replacing the washers ( 37 ) and the piston ( 36 )
with other components having different characteristics.
WARNING
Only use original Marzocchi washers and pistons, do not modify the
components.
with the segment (35), the washer or the washers stack regulating the rebound
(37), following this order.
63
73
43
33
53
