Problem Possible cause Solution
The lights are not on (if so
equipped)
The engine is not running. Start the engine.
The cable connection is loose.
Do a check of the cable connections
at the engine and the lights.
The LED is burnt out.
Replace the LED light module. Indi-
vidual LEDs can not be replaced.
The fuse is blown.
Replace the fuse. Make sure that
there is no short circuit.
The chute rotator is diffi-
cult to move
There is debris in the chute rotator mechanism.
Clean the internal parts of the chute
rotator mechanism.
The cables are kinked or damaged.
Make sure that the cables are not
kinked. Replace the cables that are
damaged.
The release cable needs adjustment. Adjust the release cable.
The product turns to one
side
The tire pressure is not equal.
Adjust the tire pressure and fill the
tire.
The product drives with only one wheel. Inspect the tire lock pin.
Uneven sled adjustment. Adjust the skid plates and the sledge.
Uneven skid plates adjustment. Adjust the skid plates and the sledge.
The product moves when
the drive speed lever is in
the neutral position.
The neutral position is not set correctly.
Adjust the neutral position. Refer to
To adjust the neutral position on
page 18
.
EFI Error Codes
Note: There is an error indicator on the body of the
engine throttle to show errors for parts without software.
Error code Error names
Error indicator continuously
flashes times
P0261 Injection error. 1
P0230 Fuel pump error. 4
P0350 Ignition coil error. 8
P0650 Error indicator fault. It is only possible to use
OBD to read the error
code.
P0123 Electrically short circuit in the throttle position sensor. 7
P0122 Electrically short ground in the throttle position sensor.
P0120 Error in throttle position sensor.
P0118 Electrically short circuit in the sensor for cylinder cover
temperature.
5
P0117 Short circuit to ground in sensor for cylinder temperature.
876 - 019 - 05.10.2023 27
