12 BRAKE SYSTEM
82
Warning
Danger of accidents Brake linings which have not been approved alter the braking efficiency.
Not all brake linings are tested and approved for Husqvarna motorcycles. The structure and friction
coefficient of the brake linings, and thus their brake power, may vary greatly from that of original brake
linings.
If brake linings are used that differ from the original equipment, compliance with the original homolo-
gation is not guaranteed. In this case, the vehicle no longer corresponds to its condition at delivery
and the warranty shall be void.
– Only use brake linings approved and recommended by Husqvarna motorcycles.
Warning
Environmental hazard Hazardous substances cause environmental damage.
– Dispose of oils, grease, filters, fuel, cleaning agents, brake fluid, etc., correctly and in compliance
with the applicable regulations.
Info
Never use DOT 5 brake fluid. It is silicone-based and purple in color. Oil seals and brake lines are not
designed for DOT 5 brake fluid.
Avoid contact between brake fluid and painted parts. Brake fluid attacks paint.
Only use clean brake fluid from a sealed container.
K00997-10
– Stand the vehicle upright.
–
Remove screws
1
.
–
Take off the cover with the washer and membrane
2
.
– Press the brake piston back into the basic position and
ensure that brake fluid does not flow out of the brake fluid
reservoir; if necessary, draw some off.
K00999-10
–
Take off cotter pin
3
and remove pin
4
.
–
Take off retaining spring
5
and remove the brake linings.
– Clean the brake caliper.
K01000-01
– Position new brake linings.
Info
Always change the brake linings in pairs.
