M.42 Part. N. 8000 H1489 (10-2009)
ELECTRICAL SYSTEM
• Securing the wiring (TC)
Strap wiring to chassis with three clips (7) as shown in the gure.
• Securing the engine stop button cable (TC)
Secure the engine stop button cable (8) with two clips (9).
• Securing the wiring (TC)
Secure the ignition and gear sensor wiring loom to the clutch hose.
