SPECIFICATIONS - OPERATION - MAINTENANCE
EN - 33
EN
CLUTCH LEVER FREE PLAY ADJUSTMENT
Free play (A) must be 5 -10 mm (0.196 - 0.39 in).
- Move the rubber gaiter (1);
- regulate the adjuster screws (2) and the counter ad-
juster screw (3) to obtain the indicated free play.
- after completing the operation, make sure the counter
adjuster screw (3) is properly tightened and then re-
place the rubber gaiter (1).
SUSPENSION
The vehicle leaves the factory with standard settings for
the front and rear suspension that meet most require-
ments.
The front fork cannot be regulated in any way. On the
rear shock absorber, the spring preload and the rebound
hydraulic damping can be regulated.
SHOCK ABSORBER SPRING PRELOAD ADJUSTMENT
- Adjust the ring nut (1) using the spanner provided; by
turning left “A”, the preload increases;
by turning right “B” the preload decreases.
WARNING*: Be careful not to touch hot
exhaust pipe while adjusting the shock
absorber.

Husqvarna TR650 STRADA Specifications

General

Displacement	652 cc
Bore x Stroke	100 mm x 83 mm
Fuel System	Electronic fuel injection
Transmission	6-speed
Seat Height	860 mm
Dry Weight	168 kg
Starter	Electric
Final Drive	Chain
Cooling System	Liquid cooled
Rear Suspension	Monoshock
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	110/80 R19
Power	58 hp
Torque	60 Nm
Engine Type	Single cylinder, 4-stroke
