Husqvarna VIKING Onyx 15 User Manual

B
A
D
C
Model Onyx 15
Model Onyx 25
S1
S2
Operating Your Machine – 17
OPERATING YOUR MACHINE
SELECT A STITCH
For sewing the grey stitch patterns
For sewing the S1 or S2 stitch patterns
Turn the Stitch Selector Dial until it clicks in place under the
dot directly above the dial on the machine.
Set the Stitch Length Dial according to the length you want.
It can be set anywhere between 0.5 and 4, with 4 being the
longest setting.
For straight stitch sewing, the Stitch Width Dial (Onyx 25
only) can be set at 0 for the center needle position or 6 for the
left needle position.
The stitch selector dial is used to select the stitch you want to sew. The dial can be turned to the left or to the right.
A. Reverse sewing lever
B. Stitch width dial (model Onyx 25)
C. Stitch length dial
D. Stitch selector dial
Stitch Width Dial
Stitch Width Dial
Stitch Length Dial
Stitch Length Dial
Turn the Stitch Selector Dial until it clicks in place under the
dot directly above the dial on the machine.
Set the Stitch Length Dial so that the S1 or S2 is lined up with
the dot above this dial. This dial must be set at the S1 marking
for the blue stitches or the S2 marking for the grey stitches, or
the stitch pattern will not sew.
Set the Stitch Width Dial (Onyx 25 only) to a wide setting (4-
6). If desired, you can set it to a lower setting, depending on
the look you want.
OPERATING YOUR MACHINE

Husqvarna VIKING Onyx 15 Specifications

General

Type	Mechanical
Stitches	15
Maximum Stitch Width	5 mm
Maximum Stitch Length	4 mm
Needle Threader	Yes
Drop Feed	Yes
Free Arm	Yes
Included Presser Feet	Buttonhole foot, Zipper foot
