LAMP REPLACEMENT
Fluorescent lamps must be replaced by lamps
of the same size dimension and wattage as the
original. Restocked beer may freeze.
ARV-570 (Only) Interior Top
1. Unplug the unit.
2. Remove lamp assembly from the unit.
3. Remove lamp from the end cap.
4. Remove lamp from plastic shield.
5. Replace the lamp.
6. Put into clear sleeve.
7. Reassemble in reverse order.
8. Plug the unit in.
9. Allow the unit to run for at least 30 minutes
before stocking with fresh product.
14
Safe-NET software Version 9.03 or later
1 October 2009 — P/N 0512887_A
ARV-570 & ARV-1230 ARV-570 & ARV-1230
©2009 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
End Cap
Fluorescent Lamp
Aftermarket Part # Description
BU.4481507 T8 18W (ARV-570 Lamps)
BU.4481514 T8 32W (ARV-1230 Lamps)
