Hussmann ARV-570 - ARV-1230 Interior Center Lamp Replacement

ARV-1230 (Only) Interior Center Column
1. Sell all product in the unit.
2. Unplug the unit.
3. Remove the shelves from one side.
4. Remove lamp assembly from the unit.
4. Remove lamp from end cap.
5. Remove lamp from plastic shield.
6. Replace the lamp.
7. Put into clear sleeve.
8. Reassemble in reverse order.
9. Plug the unit in.
10. Allow the unit to run for at least 30 min-
utes before stocking with fresh product.
15
P/N 0512887_A — 1 October 2009
Safe-NET software Version 9.03 or later
ARV-570 & ARV-1230
©2009 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Hussmann Beer Merchandiser
ARV-570 & ARV-1230
Plastic Shield
End Cap
Fluorescent
Lamp
End Cap
fluorescent Lamp
