ARV-570 and ARV-1230 Canopy (Exterior)
1. Unplug the unit.
2. Remove all push fasteners from canopy top
and bottom. (There is an equal number of
push fasteners on top and bottom.)
3. Carefully remove the canopy.
4. To remove the fluorescent lamp, disconnect
the two individual wire connector from each
end.
5. Remove from holding clips.
6. Replace the lamp and reconnect connectors.
7. Reassemble in reverse order.
8. Plug the unit in.
9. Allow the unit to run for at least 30 minutes
before stocking with fresh product.
16
Safe-NET software Version 9.03 or later
1 October 2009 — P/N 0512887_A
ARV-570 & ARV-1230
©2009 HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
U.S. & CANADA 1-800-922-1919 • MEXICO 1-800-522-1900 • WWW.HUSSMANN.COM
Wire Connector
Wire Routing
