46 sErvIcE
REPLACING CONDENSER MOTOR
Unplug the power cord before servicing.
1. Remove product and place in a refrigerated area. Make sure the power is off to the case.
2. Make sure there is no voltage in the refrigerator. Remove rear lower panel as shown in the
illustration.
3. Slide out the condensing unit. Be careful using the condensing unit base to pull it out. Make
sure not to stress or interfere with other parts.
VRL3B1A Shown
Parts may be ordered at Hussmann’s Performance
Parts e-store:
https://parts.hussmann.com/
or
Call toll free: 855-487-7778
Required Tools:
• Screwdriver / Philips Tip
• 1/4" Allen Wrench
REMOVE CONDENSING UNIT
STOPPER
A
To Next Page
