8 InstallatIon
PN_3155541_C U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • www.hussmann.com
MODEL DESCRIPTION
VRL merchandisers are low temperature self-
contained cabinets, designed for pre-packaged
frozen food or products that require frozen
temperatures for conservation.
Design Features:
- Contemporary styling places maximum
attention on merchandising
- All VRL merchandisers have the same access
panel design for commonality between
merchandisers
- Self-closing Innovator doors. Positive seal,
torsion type closure system
- Triple-pane thermal insulated glass door
assemblies
- Magnetic door gaskets of one-piece
construction, removable without tools for
ease of cleaning
- Merchandiser can be placed against wall -
no air gap is required behind the case
- Digital display in center of case air grille
CABINET LEVELING
This merchandiser must be installed level
(from back to front, and side to side) to allow
maximum draining of the condensate water as
well as proper door alignment and operation.
Choose a level area to install case.
These cases have adjustable leg leveler at
center front and back. Turn the leg levelers
clockwise to add length to each leg for leveling.
Adjustable
Leg Levelers
GDF 3.0 SHEET SIZE D
NOTES:
1. APPLICABLE STANDARDS / SPECIFICATIONS
ASME Y14.5M-1994, DIMENSIONS AND TOLERANCES
2. KEY PRODUCT CHARACTERISTICS PER EPR-0006 & IDENTIFIED WITH SYMBOL
3. MATERIAL-
4. REF -
K
SHEET 2 OF 12
P/N
REV
THIRD
ANGLE
PROJECTION
UNLESS OTHERWISE SPECIFIED
DIMENSIONS ARE IN INCHES.
R
A
A
SECTION A-A
INSTALLATION
To Next Page
