40 tEchnIcal InforMatIon
VRL Replacement Parts List
(Continued)
Models VRL1B VRL2B VRL3B
Models VRL1B VRL2B VRL3B
StandardParts
Description PartNumber
PowerCord(NEMAL6‐15P) 3042765 XX
PowerCord(NEMAL6‐20P) 3024764 X
LightSwitch 3038707 XXX
SensorNTC4mtsGreen 3023554 XXX
SensorNTC4mtsOrange 3031571 XXX
ControlEliwellRTN400 3023537 XXX
ControlDisplayKDE 3023552 XXX
MainSwitch 3038707 XXX
SolidStateRelay25Amp 3025263 XXX
Rail‐Shelf(50") 3015493 XXX
ShelfClips(insertintoRail‐Shelf) 3009285 XXX
DefrostHeaterLimitThermostat 0344662 XXX
WireShelf(White)21X24.812 3041925 X
WireShelfBottom(White)21X24.812 3041926 X
WireShelf(White)21X24.312 3015794 XX
WireShelfBottom(White)21X24.312 3015795 XX
LedLightCTR4000K 3024564 XX
LedLightRH4000K 3024573 XX
DoorBlackLowTempLH 3017269 XXX
DoorTorsionDoorAssy 3017256 XXX
DoorGasket 3017271 XXX
DoorHandle 051007300 XXX
Models VRL1B VRL2B VRL3B
UpperLightedDisplay
WhitePlexiglassDisplay1Door 3041296 X
WhitePlexiglassDisplay2Doors 3020063 X
WhitePlexiglassDisplay3Doors 3016789 X
PowerSupply100W24VDC 3013744 XXX
LedLightDisplay 3004888 X
LedLightDisplay 3004891 X
LedLightDisplay 3004897 X
MagneticClipforLedLight 0523762 XXX
Models VRL1B VRL2B VRL3B
Heaters
DefrostHeaterRH 3019313 X
DefrostHeaterLH 3021344 X
DefrostHeater1Door 3040716 X
DefrostHeater2Door 3037292 X
DefrostHeaterEvapPan1Door 3040717 X
DefrostHeaterEvapPan2Door 3037293 X
DefrostHeaterEvapPan3Door 3021337 X
HeaterTubeDrain 3025128 XXX
HeaterFrame208V1DoorsLtemp 3034074 X
HeaterFrame208V2DoorsLtemp 3034075 X
HeaterFrame208V3DoorsLtemp 3017242 X
Models VRL1B VRL2B VRL3B
SheelMetalReplacementPartsPainted
SupportPostRearPanel 3015489 X
SupportPostRearPanel 3074230 X
SupportPostShelf 3015492 XX
PanAssy‐Evap1Doors 3041395 X
PanAssy‐Evap2Doors 3020069 X
PanAssy‐Evap3Doors 3022670 X
FrontGrillAssy1Doors 3041170 X
FrontGrillAssy2Doors 3018400 X
FrontGrillAssy3Doors 3016857 X
ExtRearBottomPanel1Doors 3041401 X
ExtRearBottomPanel2Doors 3020018 X
ExtRearBottomPanel3Doors 3015027 X
Models VRL1B VRL2B VRL3B
Refrigeration
CondenserUnitAssyLH 3016595 X
CondenserUnitAssyRH 3016596 X
CondenserUnit 3039076 X
CondenserUnitAssy 3040873 X
CompressorR290208V/60Hz 3018571 XX
CompressorR290208V/60Hz 3037650 X
Condenser 3016607 XXX
CondenserFanMotorAssy115V‐230V(MotorBlade&Brkt) 3050263 XXX
EvaporatorCoil 0534325 X
EvaporatorCoil 0547179 X
EvaporatorCoil 0547180 X
EvaporatorFanMotor900RPM 3055125 XX
EvaporatorFanMotor1200RPM 3055126 X
EvaporatorFanBlade8.25" 3055130 XX
EvaporatorFanBlade7.00" 3055131 X
EvaporatorFanMotorBracket 3058806 XXX
DistributorOrifice1/4 3020663 XXX
CapillaryTube.050"x120 3020534 XX
CapillaryTube.054"x130 3037649 X
FilterDrier704‐200 0530462 XXX
Models VRL1B VRL2B VRL3B
Models VRL1B VRL2B VRL3B
StandardParts
Description PartNumber
PowerCord(NEMAL6‐15P) 3042765 XX
PowerCord(NEMAL6‐20P) 3024764 X
LightSwitch 3038707 XXX
SensorNTC4mtsGreen 3023554 XXX
SensorNTC4mtsOrange 3031571 XXX
ControlEliwellRTN400 3023537 XXX
ControlDisplayKDE 3023552 XXX
MainSwitch 3038707 XXX
SolidStateRelay25Amp 3025263 XXX
Rail‐Shelf(50") 3015493 XXX
ShelfClips(insertintoRail‐Shelf) 3009285 XXX
DefrostHeaterLimitThermostat 0344662 XXX
WireShelf(White)21X24.812 3041925 X
WireShelfBottom(White)21X24.812 3041926 X
WireShelf(White)21X24.312 3015794 XX
WireShelfBottom(White)21X24.312 3015795 XX
LedLightCTR4000K 3024564 XX
LedLightRH4000K 3024573 XX
DoorBlackLowTempLH 3017269 XXX
DoorTorsionDoorAssy 3017256 XXX
DoorGasket 3017271 XXX
DoorHandle 051007300 XXX
Models VRL1B VRL2B VRL3B
UpperLightedDisplay
WhitePlexiglassDisplay1Door 3041296 X
WhitePlexiglassDisplay2Doors 3020063 X
WhitePlexiglassDisplay3Doors 3016789 X
PowerSupply100W24VDC 3013744 XXX
LedLightDisplay 3004888 X
LedLightDisplay 3004891 X
LedLightDisplay 3004897 X
MagneticClipforLedLight 0523762 XXX
Models VRL1B VRL2B VRL3B
Heaters
DefrostHeaterRH 3019313 X
DefrostHeaterLH 3021344 X
DefrostHeater1Door 3040716 X
DefrostHeater2Door 3037292 X
DefrostHeaterEvapPan1Door 3040717 X
DefrostHeaterEvapPan2Door 3037293 X
DefrostHeaterEvapPan3Door 3021337 X
HeaterTubeDrain 3025128 XXX
HeaterFrame208V1DoorsLtemp 3034074 X
HeaterFrame208V2DoorsLtemp 3034075 X
HeaterFrame208V3DoorsLtemp 3017242 X
Models VRL1B VRL2B VRL3B
SheelMetalReplacementPartsPainted
SupportPostRearPanel 3015489 X
SupportPostRearPanel 3074230 X
SupportPostShelf 3015492 XX
PanAssy‐Evap1Doors 3041395 X
PanAssy‐Evap2Doors 3020069 X
PanAssy‐Evap3Doors 3022670 X
FrontGrillAssy1Doors 3041170 X
FrontGrillAssy2Doors 3018400 X
FrontGrillAssy3Doors 3016857 X
ExtRearBottomPanel1Doors 3041401 X
ExtRearBottomPanel2Doors 3020018 X
ExtRearBottomPanel3Doors 3015027 X
Models VRL1B VRL2B VRL3B
Refrigeration
CondenserUnitAssyLH 3016595 X
CondenserUnitAssyRH 3016596 X
CondenserUnit 3039076 X
CondenserUnitAssy 3040873 X
CompressorR290208V/60Hz 3018571 XX
CompressorR290208V/60Hz 3037650 X
Condenser 3016607 XXX
CondenserFanMotorAssy115V‐230V(MotorBlade&Brkt) 3050263 XXX
EvaporatorCoil 0534325 X
EvaporatorCoil 0547179 X
EvaporatorCoil 0547180 X
EvaporatorFanMotor900RPM 3055125 XX
EvaporatorFanMotor1200RPM 3055126 X
EvaporatorFanBlade8.25" 3055130 XX
EvaporatorFanBlade7.00" 3055131 X
EvaporatorFanMotorBracket 3058806 XXX
DistributorOrifice1/4 3020663 XXX
CapillaryTube.050"x120 3020534 XX
CapillaryTube.054"x130 3037649 X
FilterDrier704‐200 0530462 XXX
Component parts are
specifically chosen for
propane exposure and
therefore non-incendive and
non-sparkling. Component
parts shall be replaced with
identical components, and
servicing shall be done by
factory authorized service
personnel only, so as to
minimize the risk of possible
ignition due to incorrect parts
or improper service.
