Hussmann R3B - Wiring Diagrams

THIRD
ANGL
E
PROJECTION
UNLESS OTHERWISE SPECIFIED DIMENSIONS ARE IN INCHES.
APPROVED BY - CRAIG BOOREY
TOLERANCES ARE:
DECIMALS .XX
u
.03, .XXX
u
.010
ANGLES
u
2
v
MATERIAL - N/A DATE DRAWN - 10-4-16 DRAWN BY -CRAIG BOOREY REVIEWED BY -CRAIG BOOREY
ECN-CAP-0004590
REF -
3016443
DIAGRAM-R3/CR3- 4- R DELI/BAKERY
REV
A B C D
ECN
ECN-CAP-0004 590 ECN-CAP-0005979 ECN-CAP-0006207 ECN-COD-0015253
DATE
2016/10/04
2017/01/13
2017/01/25
2022/02/08
REV BY
CB
CB CB AL
CHKD BY
CB
CB CB CB
APPR BY
CB CB CB CB
REVISION HISTORY
REVISION DESCRIPTION
RELEASED TO PRODUCTION
REVISED REAR STORAGE COIL
REVISED REAR STORAGE T-STAT
NEW LIGHTS
NOTES: CASE MUST BE GROUNDED WHEN PASSING WIRES THROUGH METAL HOLES A GROMMET MUST BE USED
D
SHEET 1 OF 2
CIRCUIT #1
LOADING
120V
1.7L1
T-STAT (1) 225-01-070 7
TOP SECTION
BUNDLE WHITE/BLACK
TOP SECTION
BUNDL E BROWN MBR
HTR ELMT 55" 100W 0.93A @ 120V 1H36820550
BUNDL E PURPLE MP
FRONT LOWER SECTION
L1
N
~120 VAC - 60 Hz
BLK # 14
WHT # 14
BLK # 14
WHT # 14
L1
N
~120 VAC - 60 Hz
BLK # 14
WHT # 14
L1
N
FAN MOTOR 0.12 AMP @120VAC (2) 0477653
M M
MCA= 0.30A MOP= 15A
~120 VAC - 60 Hz
MCA= 1.16A MOP= 15A
T-STAT (1) 225-01-0705A
SUCTION SOLENOID .14A @ 120VAC
L L
LIGHT SWITCH TIPPETTE 125-01-031 1
BUNDLE ORANGE MO
BLK # 14
L1
N
~120 VAC - 60 Hz
MCA= .14A MOP= 15A
WHT # 14
LIGHT SWITCH TIPPETTE 125-01-031 1
LOWER FRONT SECTION
TOP SECTION
LIGHT CIRCUIT= .11A 12.4W
LED DRIVER
LED DRIVER
BLK # 14
WHT # 14
L1
N
~120 VAC - 60 Hz
FAN MOTOR 0.12 AMP @120VAC (2) 0477653
M M
MCA= 0.30A MOP= 15A
4' LED LIGHT - ULT
4' LED LIGHT
-ULT
BUNDLE BROWN MBR
RED +
BLACK -
RED +
BLACK -
