Hussmann RL - Nut Retainer Installation; Left-Hand End Nut Retainer Installation; Right-Hand End Nut Retainer Verification

Reach-in Rectangular Solid
and Contour Glass Ends
P/N 0387152_H
3
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
1
For Left-Hand end, install
Nut Retainers – 1 as shown in
Figure 2. If installing a right-
hand end, verify that Nut
Retainers are in place.
For Right-Hand end, remove
alignment pin shown in Figure 3.
Figure 2. Install Nut Retainers
1
RL / RM /
RMF
and
RLN / RMN
RLNI
Figure 3.
Remove Alignment Pin
Alignment Pin
RLT
