Hussmann RL - Gasket Application for RL;RM;RMF & RLN;RMN; Apply Donut Gasket to Left End; Apply Foam Tape Gasket to Right End

P/N 0387152_H
4
HUSSMANN CORPORATION • BRIDGETON, MO 63044-2483 U.S.A.
2
Apply Donut Gasket – 1 in
recess around left end as shown
in Figure 4A, Part 1; 4B or 4C,
Part 1, and right end frames as
shown in Figure 4A, Part 2; 4B
or 4C, Part 2.
Apply the wider Foam Tape
Gasket — 2 around the right
end frame as shown in Figure 4A,
Part2, 4B or 4C, Part 2.
Figure 4A, Part 1. Apply Gasket to Left End of RL/RM/RMF and RLN/RMN
RL / RM / RMF
and
RLN / RMN
Left End Case
Left End Case
Right End Case
1
Use only one Gasket Pad Sealer for each case joining.
