109632 09/08 2-9
Gearbox Sub-Assembly—72" Deck
NOTES:
1. The center line of 467324 (Drive Pulley) must sit 1.86±.06" below the bottom
surface of 109795 (Gearbox Mount W/A).
2. Torque to 67-75 ft. lbs.
3. Service part includes safety decal and rivet nuts (Item 16); see “Deck Decals” on
page 4-2.
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 601643 601643 1 FLEXIBLE JOINT COVER
2 058776 058776 3 NT .312-18 HXZY NL
3 079202 079202 3 FW .344X 1.380X.12 ZN
4 037887 037887 3 CB .312-18X 1.000 FUL Z
5 109829 109829 1 PIVOT BRACKET SHIELD
6 746263 746263 1 CS .312-18X5.50 HX G5 Z
7 110524 110524 1 ANCHOR BRACKET SHIELD
8 767954 767954 2 FW .406X .812 X.060 SAE
9 029751 029571 2 CS .375-16X1.000 HXFLK
10 078949 078949 4 CS .500-13X2.000 G5 ZNY
11 767962 767962 8 FW .531X 1.063X.090 SAE
12 601641 601641 1 GEAR BOX
13 036715 036715 1 WOODRUFF 1/4X7/8 SAE A
14 109562 109562 2 GEARBOX SPACER
15 549725 109795 1 GEARBOX MOUNT W/A
16 600994 600994 2 3/8-16 THREAD RIVET NUT
17 781567 781567 4 NT .500-13 H8ZY NL
18 467324 467324 1 DRIVE PULLEY
19 706168 706168 2 NT .375-16 HX JAM GR5 Z
20 042051 042051 2 SS .375-16X 1.00 SQ-HD
