109632 09/08 2-19
Spindle Assembly—601630
NOTES:
ITEM
NO.
SERVICE
PART NO.
MFG.
PART NO.
QTY. DESCRIPTION
1 601725 N/A 2 SPINDLE END CAP
2 601726 N/A 2 SPINDLE BEARING
3 601723 N/A 1 SPINDLE HOUSING
4 601724 N/A 1 SPINDLE SHAFT
5 012005 N/A 1 GREASE FITTING
1
6
2
3
4
5
2
1
