109632 09/08 2-13
Carrier Arm Assembly—72" Deck
NOTES:
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 766428 766428 1 HITCH PIN COTTERLESS
2 063578 063578 2 CE .750X3.50 .150X3.32
3 023036 023036 2 HP .148 X2.690 ZN
4 084749 084749 4 FW .750X 1.500X.156 SPL
5 601578 601578 2 RELEASE PIN
6 601579 601579 2 SPRING (ROLL) PIN
7 601580 601580 2 COMPRESSION SPRING
8 767962 767962 2 FW .531X 1.063X.090 SAE
