109632 09/08 2-3
Deck Assembly
NOTES:
1. Do not torque, Item 2 (798694 Discharge Chute) must pivot freely.
2. Service part includes Item 7 (Rivet Nuts) and decals (see “Deck Decals” on
page 4-2).
INDEX NO.
SERVICE
PART NO.
MFG. PART
NO.
QTY. DESCRIPTION
1 549683 109322 1 DECK W/A 60" OUT-FRONT
549691 109785 1 DECK W/A 72" OUT-FRONT
2 798694 798694 1 RUBBER CHUTE ASSEMBLY
3 052860 052860 2 CS .375-16X1.250 HX G5
4 767954 767954 6 FW .406X .812 X.060 SAE
5 086660 086660 4 NT .375-16 HXZY NL
6 103010 103010 1 DISCHARGE CHUTE BRACKET
7 601573 601573 4 1/2-13 THREAD RIVET NUT
8 601069 601069 6 CN .312-18X.200 MAX THK
9 781567 781567 8 NT .500-13 H8ZY NL
10 767962 767962 18 FW .531X 1.063X.090 SAE
11 016527 016527 2 CS .500-13X1.00 HX G5 Z
12 109591 109591 2 GAUGE ARM MOUNT W/A
13 705954 705954 4 CS .500-13X1.25 HX G5 Z
14 017616 017616 4 CS .500-13X1.750 HX G5
15 466631 466631 2 GAGE ARM MOUNT
16 549196 N/A 2 GAUGE WHEEL ASSY
17 025395 025395 2 CB .375-16X 1.00 STD CD
18 808493 808493 2 3/8-16 THREAD RIVET NUT
19 016154 016154 2 CS .250-20X1.000 HXFLK
20 768515 768515 4 FW .281X.625X.051/.080H
21 109616 109616 2 SCALP ROLLER AXLE W/A
22 068551 068551 2 NT .250-20 HXZY NL
23 601536 601536 2 ANTI-SCALP ROLLER
