WalkBehind. (Fig. 5-15) This anti-scalp kit is
recommended to minimize scalping when mowing on rough
uneven terrain.
After setting the cutting height, adjust the anti-scalp
wheels so they extend below the deck but do not contact
the ground. They should always be at least 1/4” to 3/4” (.6
cm to 1.9 cm) below the deck. With the unit sitting on a flat
level surface, the wheel position can be adjusted up or down
as needed from 3/4” to 1-3/4” (1.9 cm to 9.5 cm) below the
blade surface. Move the wheels up or down, in 1/2” (1.3
cm) increments, using the different axle mount holes in the
wheel mount bracket. Fig. 5-13
NOTE: When the anti-scalp wheels are installed the
minimum cutting height is 1” (2.5 cm) with the anti-scalp
wheels set at 3/4”.
5-5
Figure 5-15
778845 Rev. 7/04
AAxxllee
mmoouunntt
hhoolleess
AAnnttii--ssccaallpp
wwhheeeellss
