HUSTLER MDV User Manual

606653 4-3 REV A
Fuses
The Hustler
®
MDV™ electrical system incorporates fuses to
protect it from potential damage. A blown fuse indicates that
there is an overload or short in the electrical system.
IMPORTANT: Replace a blown fuse with the same type
and size fuse.
IMPORTANT: If a fuse blows, determine what caused the
fuse to blow and resolve the problem before operating the
vehicle. If the cause can not be determined, contact your
Hustler
®
Dealer for assistance.
There are two fuse blocks located on the vehicle:
• Master fuse box
• Circuit fuse box
Master Fuse Box
The master fuse box is located under the cargo bed on the
left side of the vehicle. Access to the fuse box is through the
battery compartment. Figure 4-6
To open the master fuse box, unhook the two clamps and
remove the fuse box cover.
IMPORTANT: Never leave the fuse box cover removed
from the fuse box when operating the vehicle.
Refer to Figure 4-7 for the layout and description of the
fuses.
Circuit Fuse Box
The circuit fuse box is located under the front hood and
mounted on the firewall. Figure 4-8
Open the circuit fuse box by lifting the two yellow clips,
then squeezing the tabs on the fuse box cover. Figure 4-8
IMPORTANT: Never leave the fuse box cover removed
from the fuse box when operating the vehicle.
The following diagram (Figure 4-9) shows the layout and
description of the fuses.
A. Battery compartment door
B. Latch
Figure 4-4
A. Battery
Figure 4-5
Disconnect the negative battery cable from the
battery before opening the fuse box cover.
A
B
A
WARNING
A. Fuse box cover B. Clamps
Figure 4-6
A
B
B
