HUSTLER MDV User Manual

REV A 4-10 606653
9. If it is below the “MIN” mark, add approved brake fluid
until it is between the “MIN” mark and the top of the
reservoir. Figure 4-15.
10. Apply the brakes for a few seconds and check for fluid
leakage around the fittings.
Checking the Park Brake
To check the park brake:
1. Pull the park brake handle down to engage the park
brakes. Figure 4-20
2. Turn the ignition switch to the “PREHEAT/RUN” posi-
tion. The park brake light on the instrument panel
should light up. Figure 4-21
3. Disengage the park brakes by pulling against the park
brake handle slightly to reduce tension on the brake
latch, then, depress the brake lever release button on
the end of the lever and rotate the lever up to the fully
released position. The park brake light on the instru-
ment panel should go off. Figure 4-20 & Figure 4-21
4. If the park brake light does not come on and go off as
above, contact your Hustler
®
Dealer before operating
the vehicle.
Lifting Points
To avoid possible vehicle damage lift and block the vehicle
up only at the locations shown in Figure 4-22 & Figure 4-23.
A. Reservoir
B. “MIN” mark
C. Top of reservoir
Figure 4-19
B
C
A
D. Park brake lever and release button
Figure 4-20
E. Park brake light
Figure 4-21
Never work under the vehicle unless it is safely
supported with jack stands.
• Make certain the vehicle is secure when it is
raised and placed on the jack stands.
• The jack stands should not allow the vehicle
to move when the engine is running and the
drive wheels are rotating.
• Use only certified jack stands. Use only
appropriate jack stands, with a minimum
weight rating of 2000 pounds (907 kg) per
jack stand to block the unit up.
• Use in pairs only.
• Follow the instructions supplied with the
jack stands.
D
B
C
A
E
WARNING
