REV A 6-6 117373
NOTE: The following notes are the same for the different decks shown.
1. There is no tension adjustment of this belt
2. Route belt as shown.
42" Deck Belt Routing
52" Deck Belt Routing
Figure 6-15
Figure 6-16
