604345 4-7 REV F
reaches the change filter red line. Check the indicator daily and
replace element as needed or annually whichever occurs first.
Reset the indicator by pushing in on the yellow button after
each element change. Figure 4-9
General Engine Maintenance
Detailed instructions and recommendations for break-in and
regular maintenance are specified in the Engine Owner’s
Manual. Please refer to this manual for engine servicing,
lubricating oil levels with quality and viscosity
recommendations, bolt torques, etc. The engine warranty is
backed by the manufacturer. Special attention should be paid to
applicable data which will not be duplicated here.
Carbon canister
Some Hustler Super 104 mowers will have a carbon canister
incorporated into the fuel system. Figure 4-10
This is a mandatory feature that is required on all mowers
using gasoline engines that are put into operation in California.
These canisters should be replaced every 5 years or if they
become damaged..
Fuel Evaporation System Filter
Some Hustler
®
Super 104 mowers have a fuel evaporation
system filter. This filter must be checked and replaced every 500
hours or annually whichever comes first. Figure 4-10 & Figure
4-11
Belts
Inspect belts frequently for wear and serviceability. Replace a
belt that shows signs of severe cuts, tears, separation, weather
checking and cracking, or burns caused by slipping. Slight
raveling of belt covering does not indicate failure, trim ravelings
Figure 4-9
Figure 4-10
Figure 4-11
Carbon
canister
Fuel evaporation
system filter
Fuel evaporation
system filter
Carbon
canister
Fuel evaporation
system filter
