Huvitz CAB-4000 - Table of Contents

2
Auto Blocker
Contents
1. INTRODUCTION .................................................................................................................................. 4
1.1. S
YSTEM CONFIGURATION .............................................................................................................. 4
1.2. R
EPAIR PROCEDURE ...................................................................................................................... 6
1.3. C
AUTIONS ..................................................................................................................................... 7
1.4. V
ERSION INFORMATION ................................................................................................................. 7
1.5. O
PTICAL SYSTEM .......................................................................................................................... 8
1.6
MEASUREMENT PRINCIPLE .............................................................................................................. 10
2. CALIBRATION CONFIGURATION ............................................................................................ 11
2．1
CALIBRATION MENU ..................................................................................................................... 11
2.2
LENSMETER ....................................................................................................................................... 12
2.3
BLOCKER ........................................................................................................................................... 14
2.4
TRACER .......................................................................................................................................... 15
2.5
TRACER-SIM .................................................................................................................................. 16
3. MAINTENANCE ................................................................................................................................. 17
3.1
“IT IS NEEDED TO SETUP PRISM” MESSAGE ......................................................................................... 17
3.2
“REMOVE THE OBJECT ON THE TABLE AND THEN TURN OFF/ON” MESSAGE ........................................ 18
3.3
BLOCKING POSITION CALIBRATION ................................................................................................... 19
3.4
BLOCKING AXIS CALIBRATION ........................................................................................................... 20
3.5
CALIBRATION OF THE INTERNAL LENSMETER’S CENTER .................................................................... 21
3.6
CALIBRATION OF THE INTERNAL LENSMETER’S AXIS ......................................................................... 23
3.7
TOUCH PANEL CALIBRATION .............................................................................................................. 24
3.8
MISCELLANEOUS ............................................................................................................................... 25
4. REPAIR STANDARD ...................................................................................................................... 26
4.1
REMOVING SIDE COVER ASSEMBLY .................................................................................................. 26
4.2
REMOVING COVER LCD ASSY .......................................................................................................... 28
4.3
REMOVING THE COVER FRONT ASSY ................................................................................................ 30
4.4
REMOVING THE MODULE – 1 (TRACER, IMAGE CAMERA, INNER COVER) .......................................... 32
4.5
R EMOVING THE M ODULE - 2 (B LOCKING A RM , L ENSMETER , LED, P ROJECTION A SSY ETC .) .......................... 34
4.6
REMOVING THE SMPS, GUI BOARD AND MOTOR BOARD ................................................................ 36
4.7
REMOVING THE SENSOR WITHIN THE BLOCKING ARM MODUL.......................................................... 38
4.8
REMOVING THE BLOCKING THETA AXIS ASSY ................................................................................ 40
