Hybrid DMX-200 Series User Manual

DMX 512 CONTROLLER SERIES
Action : (SCENE Review)Action : (SCENE Review)
2) Select a button (1~8) to review.SCENE
1) Select any one of the 30 banks by pressing the
buttons.BANK UP/DOWN
3) Move wheel and faders to change fixture attributes.
Notes :Notes :
Make sure you are still in MANUAL Mode.
3.3 Programming3.3 Programming
A program (bank) is a sequence of different scenes (or steps) that will be called up one after another.
In the 30 programs can be created of 8 scenes in each.controller
3.3.2CREATE A SCENE :
3.3.2CREATE A SCENE :
1 Program) Press the button until the LED blinks.
3.2.2 REVIEW SCENE OR CHASE3.2.2 REVIEW SCENE OR CHASE
Action :Action :
2) Position and sliders all the
way down.
SPEED FADE TIME
1 PROGRAM) Press the button until the LED blinks.
3) Select the you wish to include in your
scene.
SCANNERS
Notes :Notes :
Deselect Blackout if LED is lit.
This instruction assumes that you have already recorded scenes and chases on the controller. Other
wise skip section and go to programming.
Action : (CHASE Review)Action : (CHASE Review)
2) Press the button to view the step
number on the display.
TAP DISPLAY
1) Press any one of the 6 buttons.CHASE
3) Press the buttons review all scenes
in the chase.
BANK UP/DOWN
3.3.1ENTERING PROGRAM MODE3.3.1ENTERING PROGRAM MODE
A scene is a static lighting state. Scenes are stored in banks. There are 30 bank memories on the
controller and each bank can hold 8 scene memories. The controller can save 240 scenes total.
4) Compose a look by moving the and wheel.sliders
5) Tap button.MIDI/REC
6) Choose a (01~30) to change if necessary.BANK
7) Select a button to store.SCENES
8) Repeat steps 3 through 7 as necessary. 8 scenes
can be recorded in a Program.
9) To exit program mode, hold the button.PROGRAM
You can select more than one fixture.
There are 8 scenes available in every bank.
All LEDs will flash to confirm. The LED display will now
indicate the Scene number and Bank number used.
USER MANUAL
3.2 Operation3.2 Operation
3.2.1 MANUAL MODE3.2.1 MANUAL MODE
The manual mode allows direct control of all scanners. You are able to move them and change
attributes by using the channel faders.
Action :Action :
2) Select a button.SCANNER
1 AUTO DEL) Press the button repeatedly until the
MANUAL LED is lit.
3) Move faders to change fixture attributes.
Notes :Notes :
All changes made while in Manual Mode are
temporary and will not be recorded.
TAPSYNC DISPLAY button:
Press to toggle the output indicator on the LED display
between DMX values (0-255) and percentage (0-100)
9/18
