DMX 512 CONTROLLER SERIES
Item
21
24
25
22
23
Button or Fader
MIDI input port
USB Lamp socket
DMX output connector
DC Input jack
Function
For external triggering of Banks and Chases using a
MIDI device
ON/OFF power switch
2.4 Product Overview (rear panel)2.4 Product Overview (rear panel)
DMX control signal
Main power feed
Turns the controller on and off
USER MANUAL
SERIAL NO :SERIAL NO :
9V 1000mA9V 1000mA
21 22 23 24 25
