4
5. OPERATION
is heating.
USE THE LOWEST ACCEPTABLE TEMPERATURE SETTING TO
SAVE ENERGY.
TO CHILDREN OR THE INFIRM. A THERMOSTATIC BLENDING
VALVE IS RECOMMENDED IN HIGH RISK SITUATIONS.
6.
AND ANODE REPLACEMENT
DISCONNECT ELECTRICITY SUPPLY BEFORE MAINTENANCE.
A re-settable safety thermal cut-out switches off the element in the event of the
unit over-heating.
The thermal cut-out may trip occasionally in normal use. If this happens the heater
will not heat water and the element light will not come on.
The thermal cut-out is located underneath the unit behind the grey access plate.
unit for ease of access to the cutout.
Drain water from heater and locate grey access plate.
Remove the cover retaining screws and gently prise cover off.
Element ange - remove to access anode.
Thermal cutout -
Press to reset.
Element securing bolt (x4)
Allen key required to remove.
