Replacing the filter element on the fluid filter
If the fault indicator lamp "Replace filter element" [H10]" lights up, replace the
filter element on the fluid filter. For details see page 69.
T
T
o
o
c
c
h
h
a
a
n
n
g
g
e
e
t
t
h
h
e
e
f
f
i
i
l
l
t
t
e
e
r
r
e
e
l
l
e
e
m
m
e
e
n
n
t
t
,
,
y
y
o
o
u
u
n
n
e
e
e
e
d
d
t
t
h
h
e
e
f
f
o
o
l
l
l
l
o
o
w
w
i
i
n
n
g
g
:
:
Filter element N15DMxxx (quantity and type dependent on version)
Allen wrench, size 6 mm
Fork wrench, size 13 mm
To change the filter elements, proceed as follows:
1.
Switch off the unit at the main switch and
make sure it cannot be inadvertently
switched back on.
2.
Close all shut-off valves at the inlet and
outlet.
3.
Unscrew the air bleed screw (x) completely
using a 10 mm Allen wrench.
