HYDRA-RIB 211348D - Height Adjustment

14
P/N 211348D 01/03
NOTE: If height adjustment is difficult to operate, you may
have over tightened the areas indicated. Refer to Step 10
and Step 11.
Secure pole pad (36)
as shown.
24.
36
NOTE: Pole pad may
NOT be included in
this model.
NOTE: Elevator mechanism
may appear differently than
shown.
Height Adjustment
Refer to height adjustment
instructions for operating
elevator mechanism.
