HYDRA-RIB 211348D - Rear View

8
P/N 211348D 01/03
12.
Secure jack brackets (17
& 18) to lower holes in
pole as shown.
7
4
17
4
18
19
19
4
4
7
REAR VIEW
NOTE: REFER TO INSTRUCTION MANUAL ENCLOSED WITH ELEVATOR MECHANISM.
INSTALL BACKBOARD AND GOAL AFTER INSTALLATION OF ELEVATOR
MECHANISM.
