HYDRA-RIB 211348D - Page 7

7
01/03 P/N 211348D
11.
16
4
13
9
4
7
4
10
7
4
10
7
4
16
4
7
4
9
16
4
16
TWO PERSON MINIMUM REQUIRED
FOR THIS PROCEDURE. NOT
FOLLOWING RECOMMENDATION
MAY RESULT IN SERIOUS BODILY
INJURY AND/OR PROPERTY
DAMAGE.
WARNING
IMPORTANT!
Do not over tighten.
14
14
14
15
14
13
14
Cut foam stripping (14) to sizes shown and attach
to flat side of H-frame (13) as shown. Then secure
H-frame to support arms (9 & 10).
NOTE: Install H-Frame (13) with foam striping
toward backboard.
Do this strip last.
